MediaTek Dimensity 810 and 920 now official; here are all you should know

0
Mediatek CPU

MediaTek have just introduced the Dimensity 810 and Dimensity 920 5G CPU. If you don’t know, like Qualcomm and her plethora of Snapdragon varying series of CPUs, MediaTek also have a handful of CPUs, ranging from non-branded models used in cheap feature phones and accessories, to entry-level Helio A and P series, peaching all the way to 5G-enabled Dimensity series of CPUs.

For the 5G-series, you have the Dimensity 700 in the base of the hierarchy, topping all the way to the Dimensity 1200 CPU. You may even have heard of the MediaTek 1300T CPU recently, but that model in “Kompanio” series, virtually the Dimensity 1200 5G, but for tablets, and possibly PCs.

Now, the Dimensity 810 and 920 will still seat below the likes of Dimensity 1100 and 1200, but obviously tops all 700-series. In fact, the 810 and 920 are the direct successor to Dimensity 800 and 900 series respectively.

The two new comers are built on 6nm TSMC process and both have octa-core CPUs. But while the higher Dimensity 920 has dual core Cortex-A78 @2.5GHz and six core Cortex-A55 @2GHz, the Dimensity 810 offers dual core Cortex-A76 @2.4GHz and six core Cortex-A55 @2GHz. For better understanding, here is the specs of both CPUs side-by-side

Mediatek CPU

Processor Dimensity 810 Dimensity 920
Process TSMC 6nm TSMC 6nm
CPU 2x Cortex-A76 @ 2.4GHz
6x Cortex-A55 @ 2GHz
2x Cortex-A78 @ 2.5GHz
6x Cortex-A55 @ 2GHz
Memory LPDDR4x up to 16GB, UFS 2.2 (2-lane) LPDDR4x, LPDDR5, UFS 2.1,UFS 2.2, UFS 3.1
Camera 16MP+16MP, 64MP, Hardware video HDR, 2X HDR-ISP, MFNR, 3DNR, AINR, AI-Color, AI-Bokeh, Hardware Depth Engine, Warping Engine 20MP+20MP, 108MP, Hardware video HDR, 3X HDR-ISP, MFNR, 3DNR, AINR, Hardware Depth Engine, Warping Engine
Display Same: 2520 x 1080 (Full HD+) at 21:9 120Hz
Video Decode / Video Encode Same: 4K 60fps, H.264/265/VP9 / 4K 30fps, H.264/265
Graphics ARM Mali-G57 MC2 Mali-G68 MC4
Modem True Dual 5G SIM (5G SA + 5G SA) modes; SA Option2, NSA Option3 / 3a / 3x, NR TDD Band, NR FDD Band, DSS, NR DL 2CC, 200 MHz bandwidth, 4×4 MIMO, 256QAM NR UL 2CC, 2×2 MIMO, 256QAM VoNR / EPS fallback
Connectivity Dual-Band Wi-Fi 5 (a/b/g/n/ac), Bluetooth 5.1, GPS L1CA+L5 / BeiDou B1I+ B2a / Glonass L1OF / Galileo E1 + E5a / QZSS L1CA+ L5 / NavIC Integrated Wi-Fi 6 (a/b/g/n/ac/ax), Bluetooth 5.2, GPS L1CA+L5 / BeiDou B1I+ B2a / Glonass L1OF / Galileo E1 + E5a / QZSS L1CA+ L5 / NavIC
Additional features Dual 5G SIM, 5G-CA (2CC 5G Carrier Aggregation), dual VoNR, MediaTek 5G UltraSave Dual 5G SIM, 5G-CA (2CC 5G Carrier Aggregation), dual VoNR, MediaTek 5G UltraSave

In comparison to the older 900, the Dimensity 920 offers a 9% boost in gaming performance with Integrated Wi-Fi 6 and MediaTek HyperEngine 3.0. The 810 on the other hand brings 20% faster performance than the previous generation, but has MediaTek HyperEngine 2.0. Both model will be available for integration into smartphones beginning this third quarter.

Sources: One || Two
